Latest revision as of 07:13, 25 November 2025
 | This article needs additional citations for verification. (November 2024) |
| AC 47 | |
|---|---|
 AC 47 of Block 1, Ouvrage Schoenenbourg in 1940 | |
| Type | Anti-tank |
| Place of origin | France |
| Service history | |
| In service | 1930s - 40s |
| Used by | France |
| Wars | World War II |
| Production history | |
| Variants | Naval |
| Specifications | |
| Caliber | 47 mm (1.85 in) |
| Rate of fire | 20 rounds per minute |
| Muzzle velocity | 900 metres per second (3,000 ft/s) |
The AC 47 was a French anti-tank gun of 47 mm calibre. It was principally used in the ouvrages and casemates of the Maginot Line in the late 1930s; another version was created for naval use. AC stands for anti-char, char being French for "tank".[1]
The AC 47 was principally used as a defensive weapon, since its portability was intentionally limited to prevent the weapon from being turned on defending troops if a fortification was captured.[2]
Characteristics
- Length of the tube : 2.52 m (8.26 ft)
- Rifling: 16, right-handed
- Penetration: At an incidence of 30° it could penetrate 77 mm of armour at 500 metres and 56 mm at 1000 metres.
See also
References
- ↑ "L'emblématique canon de 47 modèle 34". Atlantik-Wahl (in français). Retrieved 2024-11-10.
- ↑ Truttmann 1985, pp. 178.
Sources
- Truttmann, Philippe (1985). La Ligne Maginot ou la muraille de France. Gérard Klopp. ISBN 978-2911992612.
